200#P10 Oil-Retained Wear Plate is a durable oil-retained wear plate designed for heavy-duty industrial applications. Designed to withstand extreme pressure and reduce friction, this self-lubricating P10 steel plate ensures long-lasting durability with minimal maintenance costs. Our 200#P10 Heavy Machinery Bearing Plate is a great choice for heavy machinery, mining and construction.
| Parts No. | Width | Length | Thickness | Mounting holes Pitch | Number of Screw holes | Chamfered shape | ||||||||
| W | Tol. | L | Tol. | T | Tol. | W1 | Tol. | W2 | L1 | Tol. | L2 | |||
| 200#P10-2875 | 28 | -0.1 -0.3 | 75 | -0.1 -0.3 | 10 | ±0.01 | 45 | ±0.2 | 15 | 2 | C | |||
| 200#P10-28100 | 28 | 100 | 10 | 50 | 25 | |||||||||
| 200#P10-28125 | 28 | 125 | 10 | 75 | 25 | |||||||||
| 200#P10-28150 | 28 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-3875 | 38 | 75 | 10 | 45 | 15 | |||||||||
| 200#P10-38100 | 38 | 100 | 10 | 50 | 25 | |||||||||
| 200#P10-38125 | 38 | 125 | 10 | 75 | 25 | |||||||||
| 200#P10-38150 | 38 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-4875 | 48 | 75 | 10 | 45 | 15 | B | ||||||||
| 200#P10-48100 | 48 | 100 | 10 | 50 | 25 | |||||||||
| 200#P10-48125 | 48 | 125 | 10 | 100 | 25 | |||||||||
| 200#P10-48150 | 48 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-48200 | 48 | 200 | 10 | 100 | 50 | |||||||||
| 200#P10-48250 | 48 | 250 | 10 | 45 | 25 | 3 | ||||||||
| 200#P10-7575 | 75 | 75 | 10 | 25 | 25 | 2 | A | |||||||
| 200#P10-75100 | 75 | 100 | 10 | 50 | 25 | |||||||||
| 200#P10-75125 | 75 | 125 | 10 | 75 | 25 | |||||||||
| 200#P10-75150 | 75 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-75200 | 75 | 200 | 10 | 150 | 25 | |||||||||
| 200#P10-75250 | 75 | 250 | 10 | 100 | 25 | 3 | ||||||||
| 200#P10-75300 | 75 | 300 | 10 | 100 | 50 | |||||||||
| 200#P10-100100 | 100 | 100 | 10 | 50 | ±0.2 | 25 | 50 | 25 | 4 | |||||
| 200#P10-100125 | 100 | 125 | 10 | 75 | 25 | |||||||||
| 200#P10-100150 | 100 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-100200 | 100 | 200 | 10 | 150 | 25 | |||||||||
| 200#P10-100250 | 100 | 250 | 10 | 200 | 25 | |||||||||
| 200#P10-100300 | 100 | 300 | 10 | 200 | 50 | |||||||||
| 200#P10-125125 | 125 | 125 | 10 | 37.5 | 75 | 25 | ||||||||
| 200#P10-125150 | 125 | 150 | 10 | 100 | 25 | |||||||||
| 200#P10-125200 | 125 | 200 | 10 | 150 | 25 | |||||||||
| 200#P10-125250 | 125 | 250 | 10 | 200 | 25 | |||||||||
| 200#P10-125300 | 125 | 300 | 10 | 200 | 50 | |||||||||
| 200#P10-150150 | 150 | 150 | 10 | 100 | 25 | 100 | 25 | |||||||
| 200#P10-150200 | 150 | 200 | 10 | 150 | 25 | |||||||||
| 200#P10-150250 | 150 | 250 | 10 | 200 | 25 | |||||||||
Feature
1. Likely made of durable materials for bearing use
2. Designed for smooth sliding motion, with installation - friendly holes
3. Good wear - resistance to withstand friction
Application
1. Industrial machinery and conveyor systems
2. Automotive components like sliding doors and seats
This steel graphite insert wear plate features two precision counter-sink mounting holes for secure and flush installation. The high-strength steel substrate provides exceptional load capacity up to 200 N/mm² with excellent dimensional stability. Graphite plugs embedded in the sliding surface deliver continuous maintenance-free lubrication. The counter-sink holes allow for flat-head screw mounting, providing a flush surface profile ideal for guide and sliding applications. Custom dimensions, graphite patterns, and hole configurations available for specific equipment requirements.
Counter-sink holes allow flat-head screws to sit flush with the wear plate surface, providing a smooth, uninterrupted sliding surface without protruding hardware that could interfere with motion.
Graphite inserts are mechanically retained in precision-machined pockets within the steel surface. The inserts are pressed in securely, ensuring retention during operation.
Yes. The number, position, and size of mounting holes can be customized. Additional counter-sink holes can be added based on application requirements.
Screw size depends on the plate thickness and application load. Consult engineering for specific recommendations based on your application requirements.
Replace when surface wear exceeds 0.5mm, when graphite on the sliding surface falls below 12% of original coverage, or when the plate shows signs of deformation or cracking.
